這篇文章主要介紹了C# WPF上位機實現和下位機TCP通訊的方法，小編覺得挺不錯的，現在分享給大家，也給大家做個參考。一起跟隨小編過來看看吧

下位機使用北京大華程控電源-1，上位機使用WPF。實現了電壓電流實時采集，曲線顯示。上午在公司調試成功，手頭沒有程控電源，使用TCP服務端模擬。昨天寫的TCP服務端正好排上用場。

界面如下：

服務端

服務端實在上篇基礎上實現的。需要做如下更改：

while (true)
             {
               try
               {
                 byte[] bufferDate = new byte[1024];
                 int realLen = pSocket.Receive(bufferDate);
                 if (realLen <= 0)
                 {
                   this.Invoke(addTextDelegate, pSocket.RemoteEndPoint.ToString() + "退出\r\n");
                   socketList.Remove(pSocket);
                   //客戶端退出的時候會發送一個空字節
                   pSocket.Shutdown(SocketShutdown.Both);
                   pSocket.Close();
                   return;
                 }
                 string receiveStr = Encoding.Default.GetString(bufferDate, 0, realLen);
                 switch (receiveStr)
                 {
                   case "MEAS:VOLTage:ALL?\n":
                     proxSocket.Send(Encoding.Default.GetBytes(r.Next(16,25).ToString()+ ","+r.Next(16, 25).ToString()+","+ r.Next(16, 25).ToString()));
                     break;
                   case "MEAS:CURR:ALL?\n":
                     proxSocket.Send(Encoding.Default.GetBytes(r.Next(2, 5).ToString() + "," + r.Next(2, 5).ToString() + "," + r.Next(2, 5).ToString()));
                     break;
                   default:
                     break;
                 }
                 this.Invoke(addTextDelegate, receiveStr + "from" + pSocket.RemoteEndPoint.ToString() + "\r\n");
               }
               catch (Exception ex)
               {
                 this.Invoke(addTextDelegate, pSocket.RemoteEndPoint.ToString() + "異常退出\r\n");
                 socketList.Remove(pSocket);
                 pSocket.Shutdown(SocketShutdown.Both);
                 pSocket.Close();
                 return;
               }
             }

在While循環中加入：

 switch (receiveStr)
{
　　case "MEAS:VOLTage:ALL?\n":
　　proxSocket.Send(Encoding.Default.GetBytes(r.Next(16,25).ToString()+ ","+r.Next(16, 25).ToString()+","+ r.Next(16, 25).ToString()));
　　break;
　　case "MEAS:CURR:ALL?\n":
　　proxSocket.Send(Encoding.Default.GetBytes(r.Next(2, 5).ToString() + "," + r.Next(2, 5).ToString() + "," + r.Next(2, 5).ToString()));
　　break;
　　default:
　　break;
}

模擬電源，當收到電壓查詢時，發送16~25中隨機數，由于電源是三個通道的，因此發送三個隨機數，用逗號隔開。同樣收到電流查詢，發送2~5之間的隨機數。

完整的客戶端源碼：

public partial class Form1 : Form
  {
    public Form1()
    {
      InitializeComponent();
      addTextDelegate = new AddTextDelegate(AddText);
    }
    private AddTextDelegate addTextDelegate;
    private List socketList = new List();
    public delegate void AddTextDelegate(string text);
    private void AddText(string text)
    {
      txtLog.Text += text;
    }
    Random r = new Random();
    private void btnStart_Click(object sender, EventArgs e)
    {
      //參數：尋址方式  傳輸數據方式 通信協議
      Socket socket = new Socket(AddressFamily.InterNetwork,SocketType.Stream,ProtocolType.Tcp);
      IPAddress iPAddress = IPAddress.Parse(txtIP.Text);
      //創建EndPoint

      IPEndPoint iPEndPoint = new IPEndPoint(iPAddress, int.Parse(txtPort.Text));
      //綁定端口
      socket.Bind(iPEndPoint);
      //開啟偵聽
      socket.Listen(10);
      txtLog.Text += "服務啟動開啟偵聽……\r\n";
      Thread thread = new Thread((s) =>
       {
         Socket serSocket = (Socket)s;
         while (true)//不斷接收客戶端連接
         {
           this.Invoke(addTextDelegate, "服務正在等待客戶端連接……\r\n");
           //開始接收客戶端的連接
           //阻塞當前線程，等待客戶端連接
           //客戶端連接上之后，服務端自動生成一個socket和連接的客端通信
           Socket proxSocket = serSocket.Accept();
           this.Invoke(addTextDelegate, "客戶端連接成功！\r\n" + proxSocket.RemoteEndPoint.ToString());
           //proxSocket.Send(Encoding.Default.GetBytes("連接成功！"));
           socketList.Add(proxSocket);//當前通信的socket放到集合中
           new Thread(p =>
           {
             Socket pSocket = (Socket)p;
             while (true)
             {
               try
               {
                 byte[] bufferDate = new byte[1024];
                 int realLen = pSocket.Receive(bufferDate);
                 if (realLen <= 0)
                 {
                   this.Invoke(addTextDelegate, pSocket.RemoteEndPoint.ToString() + "退出\r\n");
                   socketList.Remove(pSocket);
                   //客戶端退出的時候會發送一個空字節
                   pSocket.Shutdown(SocketShutdown.Both);
                   pSocket.Close();
                   return;
                 }
                 string receiveStr = Encoding.Default.GetString(bufferDate, 0, realLen);
                 switch (receiveStr)
                 {
                   case "MEAS:VOLTage:ALL?\n":
                     proxSocket.Send(Encoding.Default.GetBytes(r.Next(16,25).ToString()+ ","+r.Next(16, 25).ToString()+","+ r.Next(16, 25).ToString()));
                     break;
                   case "MEAS:CURR:ALL?\n":
                     proxSocket.Send(Encoding.Default.GetBytes(r.Next(2, 5).ToString() + "," + r.Next(2, 5).ToString() + "," + r.Next(2, 5).ToString()));
                     break;
                   default:
                     break;
                 }
                 this.Invoke(addTextDelegate, receiveStr + "from" + pSocket.RemoteEndPoint.ToString() + "\r\n");
               }
               catch (Exception ex)
               {
                 this.Invoke(addTextDelegate, pSocket.RemoteEndPoint.ToString() + "異常退出\r\n");
                 socketList.Remove(pSocket);
                 pSocket.Shutdown(SocketShutdown.Both);
                 pSocket.Close();
                 return;
               }
             }
           })
           { IsBackground = true }.Start(proxSocket);
         }
       });
      thread.IsBackground = true;
      thread.Start(socket);

    }
    private void btnSend_Click(object sender, EventArgs e)
    {
      string str = txtSend.Text;
      byte[] data = Encoding.Default.GetBytes(str);

      foreach (var socket in socketList)
      {
        if (socket != null && socket.Connected)
        {
          socket.Send(data);
        }
      }
    }
  }

上位機實現客戶端功能。具體如下：

1、字段和屬性

public readonly IPEndPoint TagetIPEP;
public bool IsConnected { get; set; } = false;
private Socket socket = new Socket(AddressFamily.InterNetwork, SocketType.Stream, ProtocolType.Tcp) { /*ReceiveTimeout=1000,SendTimeout=1000*/};
private Thread recListenThread;
public string ReceiveStr { get; set; }
public byte[] ReceiveByte { get; set; }

是服務器地址和端口。

是連接的狀態c+上位機與下位機通信代碼示例，這個比較重要，在發送和接收時，都要更加進行，并更新。

用于和客戶端通訊。

是監聽客戶端消息的線程。

和用來存儲客戶端發來的消息。

2、方法函數連接方法：

public bool Connect()
    {
      try
      {
        socket = new Socket(AddressFamily.InterNetwork, SocketType.Stream, ProtocolType.Tcp)
        {
          //ReceiveTimeout = 1000,
          //SendTimeout=1000
        };
        //IAsyncResult connResult = socket.BeginConnect(TagetIPEP.Address, TagetIPEP.Port, null, null);
        //connResult.AsyncWaitHandle.WaitOne(5000, true);
        //if (connResult.IsCompleted)
        //{
        socket.Connect(TagetIPEP.Address, TagetIPEP.Port);
        IsConnected = true;
          //開啟接收監聽
          recListenThread = new Thread(() =>
          {
            while (true)
            {
              try
              {
                ReceiveByte = new byte[1024];
                int realLen = socket.Receive(ReceiveByte);
                ReceiveStr = Encoding.Default.GetString(ReceiveByte, 0, realLen);
                ReceiveEvent();
                if (realLen <= 0)
                {
                  if (socket != null && socket.Connected)
                  {
                    //服務器退出
                    IsConnected = false;
                    Log.WriteLog("服務器退出！");
                    socket.Shutdown(SocketShutdown.Both);
                    socket.Close();
                    MessageBox.Show("連接斷開！");
                  }
                  return;
                }
              }
              catch (Exception ex)
              {
                if (socket != null && socket.Connected)
                {
                  IsConnected = false;
                  Log.WriteLog("服務器異常退出！", ex);
                  socket.Shutdown(SocketShutdown.Both);
                  socket.Close();
                }
                return;
              }
            }
          })
          { IsBackground = true };

          recListenThread.Start();
          return true;
        //}
      }
      catch (Exception ex)
      {
        Log.WriteLog(TagetIPEP.Address + "連接失敗", ex);
      }
      return false;
    }

連接函數返回值為bool類型，根據返回值判斷連接是否成功連接。這里每次連接都實例化了一個，因為在執行.close()后，重新打開會失敗，而斷線重連會經常用到，沒有找到更好的方法c+上位機與下位機通信代碼示例，干脆重新實例化。連接成功后，開啟監聽服務端消息的線程。這里使用了一個()事件，在接收到消息時會觸發這個事件，刷新UI界面。

發送方法：

public bool Send(string msg)
    {
      byte[] sendMsg = Encoding.Default.GetBytes(msg);
      if (sendMsg.Length > 0&&IsConnected)
      {
        if (socket != null && socket.Connected)
        {
          try
          {
            socket.Send(sendMsg);
            return true;
          }
          catch (Exception ex)
          {
            IsConnected = false;
            Log.WriteLog("發送數據失敗,目標地址" + TagetIPEP.Address, ex);
          }
        }
      }
      return false;
    }

關閉方法：

public void Close()
    {
      if (socket != null && socket.Connected)
      {
        IsConnected = false;
        recListenThread.Abort();
        Log.WriteLog("關閉連接！");
        socket.Shutdown(SocketShutdown.Both);
        socket.Close();
      }
    }

在出現異常時調用

消息接收事件：

public event Action ReceiveEvent;

每次接收消息時觸發，獲取屬性和的值，刷新UI界面。

完整代碼：

public class TCPClient
  {
    public TCPClient(/*IPEndPoint localIPEP,*/IPEndPoint targetIPEP)
    {
      //socket.Bind(localIPEP);
      TagetIPEP = targetIPEP;

    }
    public readonly IPEndPoint TagetIPEP;
    public bool IsConnected { get; set; } = false;
    private Socket socket = new Socket(AddressFamily.InterNetwork, SocketType.Stream, ProtocolType.Tcp) { /*ReceiveTimeout=1000,SendTimeout=1000*/};
    public bool Connect()
    {
      try
      {
        socket = new Socket(AddressFamily.InterNetwork, SocketType.Stream, ProtocolType.Tcp)
        {
          //ReceiveTimeout = 1000,
          //SendTimeout=1000
        };
        //IAsyncResult connResult = socket.BeginConnect(TagetIPEP.Address, TagetIPEP.Port, null, null);
        //connResult.AsyncWaitHandle.WaitOne(5000, true);
        //if (connResult.IsCompleted)
        //{

        socket.Connect(TagetIPEP.Address, TagetIPEP.Port);
        IsConnected = true;
          //開啟接收監聽
          recListenThread = new Thread(() =>
          {
            while (true)
            {
              try
              {
                ReceiveByte = new byte[1024];
                int realLen = socket.Receive(ReceiveByte);
                ReceiveStr = Encoding.Default.GetString(ReceiveByte, 0, realLen);
                ReceiveEvent();
                if (realLen <= 0)
                {
                  if (socket != null && socket.Connected)
                  {
                    //服務器退出
                    IsConnected = false;
                    Log.WriteLog("服務器退出！");
                    socket.Shutdown(SocketShutdown.Both);
                    socket.Close();
                    MessageBox.Show("連接斷開！");
                  }
                  return;
                }
              }
              catch (Exception ex)
              {
                if (socket != null && socket.Connected)
                {
                  IsConnected = false;
                  Log.WriteLog("服務器異常退出！", ex);
                  socket.Shutdown(SocketShutdown.Both);
                  socket.Close();
                }
                return;
              }
            }
          })
          { IsBackground = true };
          recListenThread.Start();
          return true;
        //}
      }
      catch (Exception ex)
      {
        Log.WriteLog(TagetIPEP.Address + "連接失敗", ex);
      }
      return false;
    }
    public bool Send(string msg)
    {
      byte[] sendMsg = Encoding.Default.GetBytes(msg);
      if (sendMsg.Length > 0&&IsConnected)
      {
        if (socket != null && socket.Connected)
        {
          try
          {
            socket.Send(sendMsg);
            return true;
          }
          catch (Exception ex)
          {
            IsConnected = false;
            Log.WriteLog("發送數據失敗,目標地址" + TagetIPEP.Address, ex);
          }
        }
      }
      return false;
    }
    public event Action ReceiveEvent;
    public string ReceiveStr { get; set; }
    public byte[] ReceiveByte { get; set; }
    public void Close()
    {

      if (socket != null && socket.Connected)
      {
        IsConnected = false;
        recListenThread.Abort();
        Log.WriteLog("關閉連接！");
        socket.Shutdown(SocketShutdown.Both);
        socket.Close();
      }
    }
    private Thread recListenThread;
  }

前臺調用，聲明Timer定時器，每個一秒觸發一次。觸發事件如下：

private string flag = "";
    private void QueryTimer_Elapsed(object sender, System.Timers.ElapsedEventArgs e)
    {
      Now = DateTime.Now;
      if (!tcp.Send("MEAS:VOLTage:ALL?\n"))
      {
        queryTimer.Enabled = false;
        StartContent = "開始";
        ConnContent = "連接";
        tcp.IsConnected = false;
        MessageBox.Show("查詢失敗！");
        return;
      }
      flag = "V";
      Thread.Sleep(50);
      if (!tcp.Send("MEAS:CURR:ALL?\n"))
      {
        queryTimer.Enabled = false;
        StartContent = "開始";
        ConnContent = "連接";
        tcp.IsConnected = false;
        MessageBox.Show("查詢失敗！");
        return;
      }
      flag = "C";
      #region 測試
      //angle += 18;
      //if (angle > 360)
      //{
      //  angle = 18;
      //}
      #endregion
    }

刷新UI界面的事件如下：

private void Tcp_ReceiveEvent()
    {
      Task.Run(() =>
      {
        Application.Current.Dispatcher.Invoke(() =>
        {
          RemoteIP = tcp.TagetIPEP.ToString();
          switch (flag)
          {
            case "V":
              VoltValue = Math.Round(Convert.ToDouble(tcp.ReceiveStr.Split(',')[0]), 3);
              break;
            case "C":
              CurrentValue = Math.Round(Convert.ToDouble(tcp.ReceiveStr.Split(',')[0]), 3);
              break;
            default:
              break;
          }
          #region 測試
          //VoltValue = Math.Round(Math.Sin((angle) * pi / 180) * 16 + 16, 3);
          //CurrentValue = Math.Round(Math.Sin((angle) * pi / 180) * 2.5 + 2.5, 3);
          #endregion
          VoltValues.Add(VoltValue);
          CurrentValues.Add(CurrentValue);
          if (VoltValues.Count > 30)
          {
            VoltValues.RemoveAt(0);
            CurrentValues.RemoveAt(0);
          }
        });
      });
    }
